97
W
orld Pr
ec
ision Instruments
A
C
B
D
E
V
O
AB
EB
Tradional thermal cautery utilizes heat in the
form of direct current to perform coagulation.
This method eliminates the possibility of
alternate site burns that can occur with
electrosurgery. Only the heated wire tip comes
in contact with the tissue and current does
not enter the patient's body. WPI's Thermal
Cautery Unit provides all the cautery power
necessary for treating numerous minor surgical
conditions and is ideal for applications such as
dermatological, ophthalmological, occupational
health, ENT, and plastic surgery cases, or any
procedure that requires accurate hemostasis.
The Thermal Cautery Unit maintains the desired
temperature during tissue contact and does
not rapidly diminish like disposable battery
powered cauteries. The autoclavable handpiece
with six-foot cord accepts an assortment of
reusable thermal cautery electrodes, allowing
the surgeon to have the flexibility to perform a
wide variety of procedures. This unit will outlast
battery-powered units and save money on
replacement batteries.
Reusable electrodes have solid 1-inch brass
shanks; tips are made with 24 gauge platinum
wire.
These general purpose electrodes are supplied
non-sterile, but may be autoclaved.
A Reusable Loop Tip General Purpose Electrode
B Reusable Fine Tip Flat General Purpose Electrode
C Reusable Loop Tip Angled Gen'l Purpose Electrode
D Reusable Ball Tip General Purpose Electrode
E Reusable Fine Tip General Purpose Electrode
O Reusable Circular Tip General Purpose Electrode
V Reusable Vasectomy Tip Electrode
AB Reusable Loop Tip Bent Perpendicular General
Purpose Electrode
EB Reusable Fine Tip Bent Perpendicular General
Purpose Electrode
Thermal
Cautery
Unit
Provides consistent,
accurate hemostasis
CAUTERY UNIT SPECIFICATIONS
LINE VOLTAGE
110V/220V, 60Hz/50Hz
OUTPUT WAVE SHAPE
Clipped Sinusoidal
OUTPUT POWER
0-30 Watts ± 6 Watts (0.2 Ohm Load)
MAXIMUM OUTPUT POWER
36 Watts (0.2 Ohm Load)
DIMENSIONS
13cm x 13cm x 20cm (dxwxh)
SHIPPING WEIGHT
5 lb (2.3kg)
Handpiece and electrodes A, C, and E are included with unit.
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
501292
Thermal Cautery Unit, 110V
501293
Thermal Cautery Unit, 220V
501294
Replacement Handpiece for 501292 & 501293
501295
Loop Tip (A) included with unit
501296
Fine Tip-Flat (B)
501297
Loop Tip-Angled (C) included with unit
501298
Ball Point (D)
501299
Fine Tip (E) included with unit
501300
Wall Bracket for 501292 & 501293
504034
Circular Tip (O)
503299
Vasectomy Tip (V)
504035
Loop Tip Bent Perpendicular (AB)
504036
Fine Tip Bent Perpendicular (EB)
