105
W
orld Pr
ec
ision Instruments
ALADDIN SPECIFICATIONS
AL-1000
AL-1000HP
SYRINGE SIZES
1-60 mL, or 0.5-5 L micro syringes Up to 60 mL
NUMBER OF SYRINGES
1
1
MOTOR TYPE
Step Motor,
1
/
8
to
1
/
2
step modes
STEPS PER REVOLUTIONS
400
200
STEPPING (max./min.)
0.21 m to 0.850 m
MOTOR TO DRIVE SCREW RATIO
15/28
15/28
SPEED (max./min.)
5.1 cm/min / 0.0042 cm/hr
18.36964 cm/min / 0.008409
cm/hr
PUMPING RATES
1699 mL/hr with 60 mL syringe,
to 0.73 L/hr with 1 mL syringe
6120 mL/hr with 60 mL syringe,
to 1.459 mL/hr with 1 mL syringe
MAXIMUM FORCE
35 lb at min. speed, 18 lb at
maximum speed
100 lb at minimum speed, 18 lb at
maximum speed
NUMBER OF PROGRAM PHASES
41
41
RS-232 PUMP NETWORK
100 pumps maximum
100 pumps maximum
POWER SUPPLY
Wall adapter 12V DC @ 850 mA
Wall adapter 12V DC @ 1000 mA
DIMENSIONS
22.9 x 14.6 x 11.4 cm
(8.75 x 5.75 x 4.5 in.)
22.9 x 14.6 x 11.4 cm
(8.75 x 5.75 x 4.5 in.)
WEIGHT
1.6 kg (3.6 lb)
1.6 kg (3.6 lb)
Aladdin
Dual Pumping Action
Need a pump for two syringes? Two Aladdin pumps when daisy-
chained are more efficient and affordable than any competitor's
dual syringe models. Two Aladdins (AL-2000) will perform as a dual
infusion/withdrawal pump, a double pump for infusing at different
rates, a push/pull pump with one infusing and one withdrawing at
the same or different rates, two independent pumps, or a master/
slave pump. One Aladdin can even control the second for continuous
pumping with optional check valve set.
The Aladdin pump series will accept syringes from Becton Dickinson,
Monoject, Terumo, and Air-Tite.
Programmable Syringe Pump
Economical
Versatile
More Features
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
AL-1000
Programmable Syringe Pump
AL-1000HP
Programmable Syringe Pump, High Pressure
AL-2000
Two AL1000 Syringe Pumps
Includes GN-TTL Interconnecting Cable for push/pull or con-
tinuous pumping. Valves not included.
Specify line voltage
When ordering 220V models, specify UK,
Euro or Australian line cord.
OPTIONAL ACCESSORIES
GN-PC7
PC to pump cable, 7 ft
GN-PC25
PC to pump cable, 25 ft
GN-NET7
Pump-to-pump network cable, 7 ft
GN-NET25
Pump-to-pump network cable, 25 ft
GN-TTL
Pump-to-pump reciprocating cable
ADPT2
Footswitch
