503738 Bur Sterilizing Tray
Half liter stainless steel tank. Du ra ble and
compact, robust all-metal con struc tion allows for
continuous duty. Includes lid.
Ultrasonic Cleaner
UBATH SPECIFICATIONS
INPUT POWER
22W
PEAK OUTPUT
70W, 55 kHz
TANK CAPACITY
0.53L (18 oz.)
TANK I.D.
12.1 x 8.6 x 6.6 cm
(4
3
/
4
x 3
3
/
8
x 2
5
/
8
in.)
TANK O.D.
13.7 x 10.5 x 12.1 cm
(5
3
/
8
x 4
1
/
8
x 4
3
/
4
in.)
SHIPPING WEIGHT
1.8 kg (4 lb.)
503737--Mesh Draining Basket
503739--Positioning Cover
SweepZone®
Ultrasonic Cleaning System
SweepZone operates with a special cleaning wave of ±2KHz energy that
literally sweeps back
and forth throughout
the ultrasonic tank.
Pulse Width Modula-
tion (PWM) enables
the device to sense
cleaning loads, solution
levels and voltage fluc-
tuations.
It automatically adjusts
to different conditions
in order to create more
uniform cleaning pow-
er by eliminating hot
spots and weak areas
in the tank. This results
in unsurpassed clean-
ing performance with
every application.
User-friendly digital touch pad controls make it easy and convenient to set
any of the five preset timer settings from a range of six to sixty minutes.
Durable stainless steel housing and tank are corrosion resistant and long
lasting. Includes timer, drain and stainless steel cover
Dimensions: 32.2 x 1.75 x 22.2 cm (12.68 x 6.88 x 8.75 in.)
Shipping Weight: 5.4 kg (12 lb)
Tank Capacity: 4.0 L (1.06 gal. )
Tank Internal Dimensions: 29.8 x 15.2 x 10.2 cm (11.75 x 6 x 4 in.)
Quantrex®
Ultrasonic Cleaning Systems
Provides super-strength
cleaning every time. Versa-
tile enough for a variety of
cleaning applications. When
used with L&R's specialty
formulated solutions, the
self-contained, compact unit
offers efficient trouble-free
cleaning. Each Quantrex
machine comes standard
with increased power--
strength you can see as
soon as you turn the unit on.
60 Minute Timer.
Constructed with vinyl-clad
steel and stainless steel.
Fourteen quality inspection steps for strength and durability.
Stainless steel drain with multi-positional outlet for easy removal of solu-
tion.
Dimensions:
26.0 x 16.5 x 21.0 cm (10.25 x 6.5
x 8.25 in.)
Shipping Weight:
4.5 kg (10 lb)
Tank Capacity:
3.2 L (0.85 gal.)
Internal Dimensions: 23.8 x 13.7 x 10.2 cm (9.38 x 5.38 x 4.0 in.)
Includes Timer, Drain and Cover. Heater Optional.
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
UBATH-Y Ultrasonic Cleaner (110 V)
UBATH-Z Ultrasonic Cleaner (220 V, Euro plug)
UBATH-B Ultrasonic Cleaner (220 V, UK plug)
Specify line voltage
13740
Ultrasonic Detergent (4 lb)
14342
Ultrasonic Detergent (1 gal)
503737 Mesh Draining Basket
503738 Bur Sterilizing Tray
503739 Positioning Cover
504217
SweepZone Ultrasonic Cleaning System
504216
Quantrex Ultrasonic Cleaning System
