111
W
orld Pr
ec
ision Instruments
Microstar OM-100
Surgical Miscroscope
Optional Accessories
Long pantographic arm (+25 cm)
(#504426)
Extension device for standard pantographic arm
(#504427)
Binocular rotating ring
(#504428)
Lens protection ring
(#504429)
Sterilizable covers kit
(#504430)
One- and two-port image splitter
(#504431)
Assistant binocular
(#504432)
Procam TV camera (integrated connection in the light
source)
(#504433)
Adaptor for digital photographic camera
(#504434)
Stand for LCD monitor
(#504435)
C-mount converter to endocoupler to use the
videocamera with endoscopes
(#504436)
Endodigi software for digital patient recording and
image filing
(#504437)
High quality wide
field optics, 5 levels of
magnification, integrated
fine focus objective lens
and fully adjustable dual
maneuvering handles.
2 illumination options, both
through a 7-mm diameter
fiber optic cable:
150 watt halogen
(double lamp)
180 watt Xenon lamp,
the ideal light for surgical
procedures
MICROSTAR OM-100 SPECIFICATIONS
MICROSCOPE
BINOCULAR TUBES . . . . . . . . . Straight / 45º Inclined / 180º Inclinable
OBJECTIVE LENS . . . . . . . . . . . Available f: 200 / 250 / 300 / 400 (
Specify when ordering)
MAGNIFICATIONS . . . . . . . . . . Manual changer 5 positions: Factor 4
×, 6×, 10×, 16×, 25×
FINE FOCUS . . . . . . . . . . . . . . . Manual integrated infocal lens
EYEPIECES . . . . . . . . . . . . . . . . 10
× wide angle. Dioptric setting: +/- 5
FIELD OF VIEW (10 X) . . . . . .
24 mm (for f: 200 mm) 31 mm (for f: 250 mm)
36 mm (for f: 300 mm) 41 mm (for f: 400 mm)
INTERPUPILAR DISTANCE . . . 55 - 75 mm
FILTER . . . . . . . . . . . . . . . . . . . . Green (orange optional)
ILLUMINATION
TYPE OF ILLUMINATION . . . . . Coaxial Illumination through 7 mm fiber optic light guide cable
ILLUMINATED FIELD . . . . . . . .
70 mm (for f: 200 mm) 90 mm (for f: 250 mm)
107 mm (for f: 300 mm) 145 mm (for f: 400 mm)
LIGHT SOURCE . . . . . . . . . . . . . HALOGEN: 2 halogen lamps (150 W 15 V each)
XENON: 180 W
POWER SUPPLY . . . . . . . . . . . . 100 - 120 VAC, 50 / 60 Hz
200 - 240 VAC, 50 / 60 Hz
FDA CERTIFIED
#2145-4-2012
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
Binocular
Arm
Light
Source
Filter
Order
Number
Price
Str
aight
Inclined
Er
gobinocular
Shor
t
Long
Halogen
Xenon
Gr
een
Or
ange
504373
504374
504375
