88
W
orld Pr
ec
ision Instruments
1.5mm Straight Plate
1.5mm T-Plates
2.0mm Straight Plates
2.0mm L-Plates
2.7mm Small Compression Plates
Mini Plates
2.7mm T- Plates
Thickness: 0.9 mm
Width: 3.8 mm
Hole Spacing: 5 mm
Thickness: 0.9 mm
Width: 3.8 mm
Length: 49 mm
FOR 20 HOLE PLATE
Thickness: 1.2 mm
Width: 5 mm
Hole Spacing: 5 mm
Thickness: 0.9 mm
Width: 5 mm
Hole Spacing: 6 mm
Thickness: 2 mm (2-6 hole)
2.5 mm (7-12 hole)
Width: 8 mm
Thickness: 1.2 mm
Width: 7 mm
Hole Spacing: 8 mm
Length: 32 mm
Thickness: 0.9 mm
Width: 5 mm
Hole Spacing: 6 mm
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
503665
Screw size: 2.7mm cortex, 32mm length, 3 holes
503615
Screw size: 1.5mm cortex, 3 holes in head, 9 holes in shaft
503616
Screw size: 1.5mm cortex, 4 holes in head, 9 holes in shaft
503614
Screw size: 1.5 mm cortex, 100mm length, 20 holes
503617
Screw size: 2.0mm cortex, 17mm length, 3 holes
503618
Screw size: 2.0mm cortex, 23mm length, 4 holes
503619
Screw size: 2.0mm cortex, 29mm length, 5 holes
503688
Screw size: 2.0mm cortex, 35mm length, 6 holes
503621
Screw size: 2.0mm cortex, 100mm length, 20 holes
503574
Screw size: 2.0mm cortex, 2 holes in shaft, Oblique Right
503575
Screw size: 2.0mm cortex, 2 holes in shaft, Oblique Left
503579
Screw size: 2.7mm cortex, 26mm length, 2 holes
503580
Screw size: 2.7mm cortex, 29mm length, 4 holes
503581
Screw size: 2.7mm cortex, 35mm length, 5 holes
504031
Screw size: 2.7mm cortex, 52mm length, 6 holes
504030
Screw size: 2.7mm cortex, 60mm length, 7 holes
503661
Screw size: 2.7mm cortex, 68mm length, 8 holes
503662
Screw size: 2.7mm cortex, 76mm length, 9 holes
503663
Screw size: 2.7mm cortex, 84mm length, 10 holes
503664
Screw size: 2.7mm cortex, 100mm length, 12 holes
