The 8L BioClave Mini comes pre-programmed for basic sterilization.
Choose either the 120ēC or 134ēC temperature mode, and the cycle time
is fixed. This is the perfect autoclave for small spaces.
The stainless steel sterilization chamber accommodates a variety of
liquids, media, instruments, glassware and plasticware. A mechanical and
electrical safety interlock prevents the door from being opened until the
pressure is released (0 PSI).
Simply press the Start button, and the entire sequence runsfill, sterilize,
exhaust and dry.
Fully automaticjust press START
Rapid, complete sterilization
Extremely compact
Built in water tank does not require connection
to an external water supply
Benchtop model
BIOCLAVE MINI SPECIFICATIONS
Chamber Volume . . . . . . . . . . . . . . . 8L
Max. Pressure . . . . . . . . . . . . . . . . . . . 29 PSI/2 Bar
Chamber Dimensions . . . . . . . . . . . . 6.7 x 12.5"/17 x 31cm
Tray Dimensions . . . . . . . . . . . . . . . . 4.75 x 9.75"/12 x 24.8cm
Exterior Dimensions . . . . . . . . . . . . . 20 x 13.5 x 12.9"/51 x 24 x 33cm
Weight . . . . . . . . . . . . . . . . . . . . . . . . 74 Lb. (33kg)
Electrical . . . . . . . . . . . . . . . . . . . . . . . 115 or 230V, 5060Hz, 950W
BioClave Mini
Research Autoclave
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 ˇ wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 ˇ wpide@wpi-europe.com US: Tel: 941-371-1003 ˇ sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 ˇ wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 ˇ wpide@wpi-europe.com US: Tel: 941-371-1003 ˇ sales@wpiinc.com
504187
BioClave Mini (115 V)
504188
BioClave Mini (230 V)
