 ISO-DAM8A Isolated, Low Noise Bioamplifier Single Channel Module



Choose Quantity
  • Overview
  • Specifications
  • Accessories
  • Citations
  • Related Products

Overview

 ISO-DAM8A Isolated, Low Noise Bioamplifier Single Channel Module

There are 1 images available to view - click to enlarge and scroll through the product gallery.

ISDB Manual (BRIDGE8/ISO-DAM8A)
/ Download as PDF

Benefits

  • Chassis accepts combination of bioamplifiers and transducer amplifiers
  • Flexible channel count (1–8) allows expandability
  • Notch filter targets AC line noise sources
  • Variable gain output amplitude
  • Wide ±10V output range

Applications

  • Amplifying biopotentials using metal microelectrodes
  • Brain slice field potentials
  • EAG (Electroantennogram)
  • ERG (Electroretinogram)

The ISO-DAM8A is a compact modular standard rack-mountable DC amplifier system. Each channel is electrically isolated from the others and from ground. No current can flow from the input terminals and electrodes. The instrument is intrinsically safe and cannot cause any electrical stimulus or shock to the preparation. In addition, ground loop noise is minimized.

Filters Included with the Amplifier

Systems can be purchased with one, two, three or up to eight preamplifier modules or mixed with Bridge8 transducer amplifier modules. You can then select:

  • An appropriate low pass filter setting, gain and offset on the channel amplifier panel.
  • Notch filter added to reduce line frequency interference.
  • Optional headstage preamplifier (10x gain) allows low noise extracellular (DC) recording with Iso-DAM8A and adds greater signal bandwidth than a shielded cable of the same length.

The Iso-DAM8A amplifier and headstage configuration is optimally suited for use with our metal microelectrodes and can be easily configured for many applications. Each amplifier channel has a coaxial (BNC) connector located on the rear panel.

Configuring Your ISDB System

The ISDB chassis (74030) holds up to eight modules and includes a power supply. You may include any combination of BRIDGE8 Transducer Amplifier modules or ISO-DAM8A single channel modules (74020). If you choose fewer than eight modules, you need to order the ISDB blank panels (74050) to fill the empty slots in the chassis. ISO-DAM8A bioampliers include an 8-pin DIN connector with shielded, unterminated 5' cable. Please specify line voltage when ordering.

When configuring your ISDB system:

  • Order a chassis and power supply enclosure (74030)
  • Select up to 8 modules (BRIDGE8)
  • Order blank panels (74050) to fill empty slots
  • 74020 is a DC amplifier

Complete eight channel amplifier system with 74030 chassis showing eight 74020 (ISODAM8A) modules installed
*Also available for BRIDGE8 transducer amplifier modules and blank panels (74050).

Iso-DAM8a

*The modules are sold separately.

Specifications

Input Impedance to Gnd, each input > 1012 Ω DC, 5 picofarads (typical)
Input leakage current 10 pA (typical)
Input DC offset ±100 mV
Gain x10, x100, x1,000, x10,000
Common Mode Rejection >100 dB @ 50/60 Hz
Equivalent noise signal input 10
Bandwidth Filter Settings
 High Filter (Low Pass) 0.1, 0.5, 1, 3, 10 kHz
 Low Filter (High Pass) 0.1, 1, 10, 300 Hz
 Notch Filter Settings 50 Hz, 60 Hz
Output voltage swing ±7.5 V
Maximum Output Resistance 220 Ω
Power Source Power Adapter 110-120V/60Hz or 220-240/50Hz
Enclosure Dimensions 18 x 43 x 23 cm
Shipping Weight 4.5–9.5 kg

Accessories

74030

74030

Isolated, Low Noise Bioamplifer Chassis

74020

74020

 ISO-DAM8A Isolated, Low Noise Bioamplifier Single Channel Module

View details...


Choose Quantity
74050

74050

ISDB Blank Panels

  • Blank panels for chasis 74030

View details...

BRIDGE8

BRIDGE8

Bridge8 Transducer Amplifier Module

View details...


Choose Quantity
74040

74040

Iso-DAM8A Active Headstage
