87
W
orld Pr
ec
ision Instruments
1.0
Pitch
2.4
Head
1.9
Core
Diameter
2.5
Hex Drive
5.0
Head
Diameter
0.5
Pitch
Cruciform
Recess
Drive
3.0
Head
Diameter
1.5
Hex Drive
1.0
Core
Diameter
1.2
Cruciate
1.6
Hex
2.0 mm Cortex Screws -- Hexagonal or Cruciate Head
Thread diameter
2.0 mm
Core diameter
1.3 mm
Thread pitch
0.6 mm
Hex screw head diameter
4.0 mm
Cruciate screw head diam
3.4 mm
Hex Socket
-- self-tapping
Cruciated Socket
-- self-tapping
Thread diameter
2.7 mm
Core diameter
1.9 mm
Thread pitch
1.0 mm
Screw head diameter 5.0 mm
2.7 mm Cortex Screws
Used in the metacarpal and metatarsal bones and also in certain indications in the radius and ulna.
Cortex Screws
-- self-tapping
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
503470
Cortex screw, hex socket, 6 mm
503471
Cortex screw, hex socket, 8 mm
503472
Cortex screw, hex socket, 10 mm
503473
Cortex screw, hex socket, 12 mm
503474
Cortex screw, hex socket, 14 mm
503475
Cortex screw, hex socket, 16 mm
503476
Cortex screw, hex socket, 18 mm
503477
Cortex screw, hex socket, 20mm
503478
Cortex screw, hex socket, 22mm
503479
Cortex screw, hex socket, 24mm
503480
Cortex screw, hex socket, 26mm
503481
Cortex screw, hex socket, 28mm
503482
Cortex screw, hex socket, 30mm
503483
Cortex screw, hex socket, 32mm
503484
Cortex screw, cruciated socket, 6mm
503485
Cortex screw, cruciated socket, 8mm
503486
Cortex screw, cruciated socket, 10mm
503487
Cortex screw, cruciated socket, 12mm
503488
Cortex screw, cruciated socket, 14mm
503489
Cortex screw, cruciated socket, 16mm
503490
Cortex screw, cruciated socket, 18mm
503492
Cortex screw, cruciated socket, 22mm
503493
Cortex screw, cruciated socket, 24mm
503494
Cortex screw, cruciated socket, 26mm
503495
Cortex screw, cruciated socket, 28mm
503496
Cortex screw, cruciated socket, 30mm
503497
Cortex screw, cruciated socket, 32mm
503498
Cortex screw, 6mm, hex socket
503499
Cortex screw, 8mm, hex socket
504029
Cortex screw, 10mm, hex socket
503648
Cortex screw, 12mm, hex socket
503649
Cortex screw, 14mm, hex socket
503650
Cortex screw, 16mm, hex socket
503651
Cortex screw, 18mm, hex socket
503652
Cortex screw, 20mm, hex socket
503653
Cortex screw, 22mm, hex socket
503654
Cortex screw, 24mm, hex socket
503655
Cortex screw, 26mm, hex socket
503656
Cortex screw, 28mm, hex scoket
503657
Cortex screw, 30mm, hex socket
503658
Cortex screw, 32mm, hex socket
503635
Cortex screw, 34mm, hex socket
503636
Cortex screw, 36mm, hex socket
503637
Cortex screw, 38mm, hex socket
503638
Cortex screw, 40mm, hex socket
