86
W
orld Pr
ec
ision Instruments
Screws and Plates
0.6
Pitch
1.3
Core
Diameter
1.5
Hex Drive
1.55
Cruciate
1.9
Hex
3.4
Cruciate Head
Diameter
4.0
Hex Head
Diameter
Cruciform
Recess Drive
1.5 mm Cortex Screws -- Hexagonal Head
Used to fix fracture fragments in the phalanges, metacarpals and small bones in the foot.
These screws may be used independently as lag screws or through a plate.
Thread diameter
1.5 mm
Core diameter
1.0 mm
Thread pitch
0.5 mm
Screw head diameter 3.0 mm
Hex Socket
-- non-tapping
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
503448
Cortex screw, hex socket, 6mm
503449
Cortex screw, hex socket, 7mm
503450
Cortex screw, hex socket, 8mm
503451
Cortex screw, hex socket, 9mm
503452
Cortex screw, hex socket, 10mm
503453
Cortex screw, hex socket, 11mm
503454
Cortex screw, hex socket, 12mm
503455
Cortex screw, hex socket, 14mm
503456
Cortex screw, hex socket, 16mm
503457
Cortex screw, hex socket, 18mm
503458
Cortex screw, hex socket, 20mm
Bending Plate
For 2.7 mm, 3.5 (2 units, R/L)
503611 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Depth Gauge
For 2.7-4.0 mm screws
503430 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hoof Knife
Narrow, right side
503436 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hoof Knife
Narrow, left side, Bakelite handle
503437 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hoof Knife
Wide blade, wood handle, left side
503435 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
