SMALL ANIMAL ANESTHESIA
EZ Anesthesia is the system of choice for anesthetizing small animals,
and it comes with a variety of choices. Animals to be anesthetized
are placed in the acrylic induction chamber and the system delivers a
precisely blended mixture of oxygen and isoflurane. An activated charcoal
air filter canister at the top of the chamber releases safe, filtered air back
into the room. A water-heated cage warmer or warming plate (ATC1000)
is used to retain the animal body temperature while in the induction
chamber. After the initial anesthetizing, the animal can be moved to the
heated surgical water bed and positioned properly in the snugly fitted
nosecone. A highly sensitive valve regulated by the animal's breathing
works with the nosecone to ensure non-rebreathing efficiency, and allow
safe anesthesia for up to several hours.
The breathing device also includes an air filter that releases safe, filtered
air back into the room.
EZ-7000 Classic System
Features
Integrated turnkey solution for small animal
anesthesia
Safe for surgical personnel, 90% below OSHA
Isoflurane limit
Designed by veterinarians
Compact and portable
Time efficient and cost effective
Virtually stress-free for the animals
Easy to setup and use, simplifying the training of new
staff and reducing the threat of human error
Speedy recovery time
EZ Systems include all necessary hardware components and connections.
Oxygen and liquid Isoflurane are not supplied. These are required to
operate the system.
Each system comes with all necessary components and connections for
immediate use, including::
Oxygen regulator
Vaporizer Unit
One Induction Chamber (standard EZ-178)
One Breathing Device (standard EZ-103)
Case of charcoal filters
Other available options include:
Heated Beds and Heating Pump
Additional Breathing Devices
EZ-FF9000 Fixed Flow System
The Fixed Flow System is our most advanced system and provides preset,
fixed flow rates with no need for adjustment. The system offers five gas
outlets, each with an individual ON/OFF switch. The system ensures
consistent, precise gas flow when connected to any pressurized gas source
higher than 7 psi.
Induction Chamber output is fixed at 1 Lpm
Four Breathing Circuit outputs are fixed at 0.5 Lpm
This unit features an oxygen flush button that purges the induction
chamber with pure oxygen, thereby protecting personnel from exposure
to anesthesia gas when opening the chamber. A handle on the vaporizer
makes the unit easy to safely transport.
EZ-7000 Classic System
The Classic System is the upgraded version of our original EZ-Anesthe-
sia system. The new version has a reconfigured flow meter that is more
user-friendly. The system offers five gas outlets that can supply a single
induction chamber and four breather circuits simultaneously.
The upgraded system also features an oxygen flush button that purges the
induction chamber with pure oxygen, thereby protecting personnel from
exposure to anesthesia gas when opening the chamber. A handle on the
vaporizer makes the unit easy to safely transport.
Components may not be as pictured.
