98
W
orld Pr
ec
ision Instruments
High Frequency Dessicator
This High Frequency Dessicator produces radio frequency current
which is useful for the removal and destruction of superficial cutane-
ous and mucosal lesions. It performs dessication and fulguration pro-
cedures.The digital power control system allows you to change from
low to high power by rotating the power knob or pushing the buttons
on the handpiece.
DESSICATOR SPECIFICATIONS
MAIN VOLTAGE
110/220 VAC
MAIN FREQUENCY
50/60 Hz
MAIN CURRENT
1.00A / 800 mA. max.
POWER CONSUMPTION
80 W
DUTY CYCLE
10S/30S
MAIN FUSES
2 x 1.25A (slow blow) 110 model
2 x 800 mA (slow blow) 220 model
HF OUTPUT CHARACTERISTICS
OUTPUT POWER
30W/1000 W
OUTPUT FREQUENCY
550 kHz
PEAK OPEN CIRCUIT VOLTAGE
5000 V
SAFETY
BASIC CONSTRUCTION
In accordance with EN 60601-1
MODE OF OPERATION
Intermittent Operation
PROTECTION
CLASS
Class 1 Equipment
OUTPUT TYPE
Type BF
DIMENSIONS
22 x 15 x 10.5 cm (8.6" x 6" x 4.2")
WEIGHT
2.25 kg (5 lb)
#501076 -- 5.5 cm
#501078 -- 5.5 cm
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
504043
High Frequency Dessicator (110V / 220V)
Dessicator Unit Includes
501085 3-button handpiece, 1 each
501076 Sharp Tip Non-sterile, 100 box
501078 Blunt Tip Non-sterile, 100 box
501084 Wall mount Kit, 1 each
OPTIONAL ACCESSORIES
501075
Footswitch
501083
Forceps Cord
OPTIONAL ACCESSORIES
Reusable Bipolar Forceps Reusable (>20 autoclaving cycles)
501005
Bipolar 71/2" Bayonet Fine (1.0 mm), Smooth, Each
501006
Bipolar 71/2" Bayonet Med. (2.0 mm), Smooth, Each
501007
Bipolar 7" Straight, Fine (1.0 mm), Smooth, Each
501008
Bipolar 7" Curved, Fine (1.0 mm), Smooth, Each
501009
Bipolar 5" Curved, Fine (1.0 mm), Smooth, Each
501010
Bipolar 51/2" Straight, Med. (2.0 mm), Smooth, Each
501011
Bipolar 5" Straight, Fine (1.0 mm), Smooth, Each
Reusable Active Electrodes
501004
Reusable Electrode, Each
501013
Angled, Sharp Electrode, Reusable, Each
501014
Short Angled, Ball, ReusableEach
501015
Short Straight, Ball, Reusable, Each
501016
Short Straight, Needle, Reusable, Each
501017
Angled, Fine Needle, Reusable, Each
501018
Long, Straight Ball, Reusable, Each
501019
Long, Straight Needle, Reusable, Each
Dispersive Electrode
501074
Reusable Dispersive Electrode for 500397
Dermal Tips 3/32" stainless steel shaft
501076
Sharp Dermal Tip, Non-Sterile, 100/box
501077
Sharp Dermal Tip, 3/32" Sterile, 50/box
501078
Blunt Dermal Tip, 3/32" Non-Sterile, 100/box
501079
Blunt Dermal Tip, 3/32" Sterile, 50/box
Unit Accessories
501080
Top Tray and Clamp Stand for 501081, Each
501081
Mobile stand for 500397
501082
Table top stainless steel stand for 500397
501083
Forceps Cord for 500397
501084
Wall Mount Kit
501085
3 Button Power Control Pencil for 500397
501075
Footswitch, Each
